Four STH Cluster Speakers with One RSS Strobe - White With FIRE Lettering Wheelock WHSTH-4R24MCCH-FW
View Larger

Four STH Cluster Speakers with One RSS Strobe - White With FIRE Lettering

Item # WHSTH-4R24MCCH-FW
Manufacturer Item # STH-4R24MCCH-FW

Log In To View
Prices		 Pixel Silver
Sold As: ea
DNR
Pixel Trans
Pixel Trans
Wheelock
More Products from Wheelock 		Pixel Silver
Product Shopping List  Add to Shopping List
Product Wish List  Save For Later
Product Bookmark  Share
Report Incorrect
Pixel Trans

Overview

Pixel Trans
Four STH Cluster Speakers with One RSS Strobe - White With FIRE Lettering
Pixel Trans
The Wheelock STH cluster speaker with RSS multi-candela strobe is designed for indoor ceiling mounting in high ambient noise environments. The cluster speaker strobe is supplied with four STH-15SR (UL1480 Listed) horns and one RSS-24MCCH (UL1971 Listed) ceiling strobe mounted to a NEMA 1 steel enclosure. The strobe is synchronizable. The STH cluster speaker with MCCH strobe comes fully assembled.

Features:
  • STH-15SR Speakers are UL Standard 1480 Listed.
  • RSS-24MCCH Strobes are UL Standard 1971 Listed
  • Compliant with ADA, OSHA 1910.165, ANSI 117.1, NFPA 72, NFPA 101, and IFC
  • Cluster and Strobe wiring can be monitored for integrity by the Control Panel
  • Cluster Speaker Strobes come fully assembled
  • High-efficiency unit for fire life safety and/or general communication announcing/notification
  • Provides high-intelligibility voice reproduction and high-intensity visual alerting for emergency life safety applications, alarm, and protective signaling
  • Speakers and Strobes are prefabricated to a 10” x 10” x 6” NEMA 1 steel enclosure for indoor use.
  • Mounts to ceiling
  • Only 1 pair of wires needed for audio connections
  • Strobes are connected to the NAC Strobe Circuit and are selectable 115 or 177 cd
  • Each individual STH-15SR horn is capable of delivering up to 102 dB at 15 watts at 10 feet
  • Omni-direction
  • Conduit knockouts for ½” or ¾” coupling
  • Labor Saving

Specifications

Pixel Trans
  Product NameFour STH Cluster Speakers with One RSS Strobe - White With FIRE Lettering
Pixel Silver
  Brand NameWheelock
Pixel Silver
  Mfg #STH-4R24MCCH-FW
Pixel Silver
  Cube2250 cu in
Pixel Silver
  Candela115 / 177
Pixel Silver
  ColorWhite
Pixel Silver
  RatingNEMA 1
Pixel Silver
  Strobe ColorClear
Pixel Silver
  UPC786697002359
Pixel Silver
Pixel Trans

Documents

Pixel Trans
Pdf STH-4R24MCCH-FW.pdf
