Gentex Corp. WGESR24-75PWR WGES Outdoor Strobe with Colored Lens" Red

The Gentex WGESR24-75PWR is an outdoor-rated strobe-only notification appliance designed to provide reliable visual signaling in fire alarm and emergency communication applications. Featuring a fixed 75 candela red strobe, this unit delivers high-visibility visual notification for outdoor environments where dependable performance is required.

The WGESR24-75PWR includes a durable GOE weatherproof enclosure for enhanced protection against environmental conditions and is designed for wall-mounted installation. The plain red faceplate (no lettering) provides a clean appearance while maintaining clear visual emergency notification.

Features:

• Nominal voltage 24VDC
• Unit is shipped with ANSI/UL1638 listed WGE colored lens strobe or horn/strobe
• Listed to ANSI/UL1638 when used with the GOE or GOELP enclosure
• GOE/GOELP made of clear Lexan® - allowing full 75cd output
• GOE Unit Dimensions: 5.75” (14.605 cm) high x 4.75” (12.065 cm) wide x 4.18” (10.617cm)
  deep
• GOELP Unit Dimensions: 5.75” (14.605 cm) high x 4.75” (12.065 cm) wide x 3.25” (8.255 cm)
  deep
• Lens colors available: amber, blue, green and red
• Super-Slide® - Ease of Supervision Testing
• Checkmate® - Instant Voltage Verification
• Prewire entire system, install mounting bracket, then install signals
• Input terminals accept 12 to 18 AWG
• Switch selection for high or low dBA
• Switch for 2400Hz, mechanical, chime and whoop tones
• Switch for continuous tone or temporal 3 (not available on whoop tone)
• Synchronize strobe and/or horn by using Gentex AVSM Control Module
• Silence audible while visual appliance will remain flashing
• Tamperproof re-entrant grill
• Faceplate available in red or off-white
• Wall mount
